Formfutura Engineering LCD Series Impact 71D Resin Clear, 500 G

Engineering LCD Resin – Impact 71D is a durable ABS-like resin with improved impact resistance. The technical resin has a Shore hardness of 71D and has excellent machinability. Printed parts can be reworked without any problems and are excellent for drilling. This makes Impact 71D resin the perfect choice for 3D printing mechanical and operational parts.

Main Features of Engineering LCD Series Impact 71D Resin

• ABS-like strength & stiffness
• High impact resistance
• Excellent machinability
• Good compatibility with all SLA, DLP and LCD / MSLA 3D printers in the range of 385 – 420nm

Applications of Engineering LCD Series Impact 71D Resin

• Strong & stiff prototypes
• Tool parts & fixtures
• Mechanical & ready-to-use spare parts
• Snap mounts
• Small batch production

Before you start printing

• Shake the bottle for at least 2 minutes before each use
• After shaking the bottle, let the resin sit for 10 minutes to allow air bubbles to escape from the resin.
• Always wear safety glasses and nitrile gloves when handling resin.

Note: Unused resin can be poured back into the bottle after the print is complete

Post-processing

• The manufacturer recommends post-processing the print in order to achieve the best material properties.
• Rinse your model in IPA or ethanol for about 5 minutes.
• An ultrasonic cleaner is recommended.
• Make sure objects rinsed with IPA and/or ethanol are perfectly dry before further post-curing.
• Place the rinsed parts in a well-ventilated area for at least 30 minutes or use compressed air for at least 2 minutes.
• Cure your object in a high-performance curing chamber for approx. 20-30 minutes at 65 ° C. The preferred curing wavelength is between 300-410 nm.
